Terminal block 222-4126 2/6 poles 0.08-2.5/4sq.mm with levers NO-225-407 (pack 15pcs) Era B0067952
SKU: Б0067952
ETIM: EC000446
22,070 ₽
Get back 220 ₽ in points
Order multiple: 15 шт
Analogues by specifications
ERA 222 series universal lever-operated feed-through branch terminal blocks are designed for creating multiple connections and duplicating contacts for all types of conductors (solid and stranded copper, terminated with NShvI ferrules) without the use of special tools.
They are used for duplicating electrical circuits when connecting lighting and other electrical equipment.
Using universal feed-through branch terminal blocks allows you to:
- create a safe branched feed-through connection if it is necessary to connect several consumers from a single power source.
- easily and quickly disconnect wires, change the circuit, or switch power to another circuit or device.
- quickly connect or extend wires made of different materials and different cross-sections.
Design features:
- the lever mechanism design ensures repeated installation and removal of all types of copper conductors with a cross-section up to 4.0 mm2: solid, stranded, and fine-wire.
- the housing design includes protrusions with mounting holes for installation on a flat surface, a mounting board, or in a junction box.
- the specially selected initial position of the lever prevents accidental disconnection of the connected conductor.
- the products feature test holes that allow for measuring the electrical parameters of the connection circuit.
- the housing is made of polyamide 6.6. It is flame retardant and halogen-free according to UL94V2.
- the contact part consists of tin-plated brass with high copper content, which guarantees good electrical conductivity and low terminal heating.
- the clamping mechanism is made of high-quality alloy spring steel, ensuring reliable conductor clamping and stable characteristics with repeated use.
Cable diameter at
2.26 мм
Cable diameter from
.32 мм
Number of clamps, terminals
8
Rated voltage
450 В
Rated cross-section at
4 кв.мм
Rated cross-section from
.08 кв.мм
Rated current
32 А
Suitable for flexible conductor
Yes
Suitable for stranded conductors
Yes
Suitable for solid conductors
Yes
With control lever
Yes
Flexible conductor with ferrule cross-section up to
4 кв.мм
Flexible conductor cross-section with ferrule from
.08 кв.мм
Rigid conductor cross-section to
2.5 кв.мм
Rigid conductor cross-section from
.08 кв.мм
Color
Light grey
