DKC
Terminal block, screw clamp, 2 connection points, 4 mm², black TUR-4R-BK DKC
SKU: TUR-4R-BK
ETIM: EC000897
64 ₽
Get back 1% in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
Feed-through terminal block with screw clamp is designed for connecting two conductors. DIN-rail OMEGA mounting. Operating temperature from -40 to +105°C. Housing made of PA 6.6 with flammability class V0 UL-94.
Black color, 2 connection points, 4 mm2. 2 channels for plug-in jumpers. Dimensions (HxWxD) 47.5x53x6.2 mm.
Version tested for explosion protection "Ex e"
No
Internally linked levels
No
Minimum possible mounting height
47 мм
Length
53.3 мм
Length
53.3 мм
Flammability class of insulation material in accordance with UL57
V0
Number of terminals per level
2
Number of poles
2
Number of levels
1
Housing insulation material
Thermoplastic
Rated voltage
1000 В
Rated current In
32 А
Closing plate can be fitted if required
Yes
Operating temperature
105 град.C
Operating temperature from
-60 град.C
Connection position
Side
With protection against contact with live parts
Yes
Core cross-section
4 кв.мм
Stranded wire cross-section with ferrule
0.14...4 мм²
Flexible stranded conductor cross-section up to
6 кв.мм
Stranded flexible conductor cross-section from
.14 кв.мм
Solid conductor cross-section to
6 кв.мм
Solid conductor cross-section from
.14 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
0.14...6 кв.мм
Mounting method
DIN rail 35 mm
Electrical connection type 1
Screw connection
Electrical connection type 2
Screw connection
Color
Black
Colour
Black
Width/connection pitch
6.2 мм
