3,360 ₽
Get back 33 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 24 шт
Analogues by specifications
Stock by warehouse
Spring terminals are designed for permanent, safe, and compact connection of conductors of various cross-sections in organized distribution systems inside electrical cabinets. Used for fastening phase, neutral, and protective conductors. The use of a spring clamping system makes the conductor connection process as simple and fast as possible. Installs on DIN rail.
It is possible to connect conductors of nominal cross-section both with cable ferrules and without prior preparation.
The insulating enclosure is made of elastic and impact-resistant fire-retardant polyamide, possessing excellent resistance to aggressive environments and temperature.
A wide range of additional accessories: plugs, marking plates, jumpers.
Length
69.70 мм
Length
69.70 мм
Design
Phase
Flammability class of insulation material in accordance with UL57
V0
Number of terminals per level
2
Number of poles
1
Number of levels
1
Housing insulation material
Other
Housing material
Polyamide 6.6
Housing material
Polyamide 6.6
Availability of PEN terminal
No
Rated voltage
800 В
Rated current In
52.0 А
Closing plate can be fitted if required
Yes
Operating temperature
85 град.C
Operating temperature from
-40...85 град.C
Connection position
Side (transverse)
Flexible stranded conductor cross-section up to
6 кв.мм
Stranded flexible conductor cross-section from
0.5...6 кв.мм
Solid conductor cross-section to
10 кв.мм
Solid conductor cross-section from
0.5...10 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
6 кв.мм
Mounting method
DIN rail (standard) 35 mm
Electrical connection type 1
Spring clamp connection
Electrical connection type 2
Spring clamp connection
Colour
Grey
Color
Grey
Width/connection pitch
8.2 мм
