IEK
Spring terminal KPI 3v-2.5 3 terminals 31A gray IEK YZN11-3-002-K03
SKU: YZN11-3-002-K03
ETIM: EC000897
5,051 ₽
Get back 50 ₽ in points
Order multiple: 45 шт
Analogues by specifications
Stock by warehouse
No description available
Length
60.80 мм
Length
60.80 мм
Design
Phase
Flammability class of insulation material in accordance with UL57
V0
Number of terminals per level
3
Number of poles
1
Number of levels
1
Housing insulation material
Other
Housing material
Polyamide 6.6
Housing material
Polyamide 6.6
Availability of PEN terminal
No
Rated voltage
800 В
Rated current In
31.0 А
Closing plate can be fitted if required
Yes
Operating temperature
85 град.C
Operating temperature from
-40...85 град.C
Connection position
Side (transverse)
Flexible stranded conductor cross-section up to
2.5 кв.мм
Stranded flexible conductor cross-section from
0.2...2.5 кв.мм
Solid conductor cross-section to
4 кв.мм
Solid conductor cross-section from
0.2...4 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
2.5 кв.мм
Mounting method
DIN rail (standard) 35 mm
Electrical connection type 1
Spring clamp connection
Electrical connection type 2
Spring clamp connection
Color
Grey
Colour
Grey
Width/connection pitch
5.2 мм
