Push-in terminals allow for maximum acceleration of the installation process and easier operation, while two jumper channels allow for the creation of various connection and power distribution schemes.
Push-in connection technology allows for a simple way to connect conductors from 1.5 to 6 mm² directly and without tools.
Special contact springs guarantee ease of insertion and high contact quality.
Length
90 мм
Length
90 мм
Flammability class of insulation material in accordance with UL57
V0
Number of terminals per level
4
Number of poles
1
Number of levels
1
Housing insulation material
Polyamide (PA)
Rated voltage
1 000 В
Rated current In
41 А
Closing plate can be fitted if required
Yes
With sealing head
No
Core cross-section
6 кв.мм
Stranded wire cross-section with ferrule
0.5...6 мм²
Flexible stranded conductor cross-section up to
6 кв.мм
Stranded flexible conductor cross-section from
0.5...6 кв.мм
Solid conductor cross-section to
6 кв.мм
Solid conductor cross-section from
0.5...6 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
0.5...6 кв.мм
Mounting method
DIN rail (O-profile) 35 mm
Electrical connection type 1
Spring clamp connection
Color
Grey
Colour
Grey
Width/connection pitch
8 мм
