DKC
Disconnect Terminal, screw clamp, 2 connection points, 4 sq.mm, gray TUR-4-MT DKC
SKU: TUR-4-MT
ETIM: EC000902
437 ₽
Get back 4 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
No description available
Internally linked levels
No
Minimum possible mounting height
49.1 мм
Length
57.8 мм
Length
57.8 мм
Cross blade design
Plug-in
Longitudinal blade design
Rotary
Flammability class of insulation material in accordance with UL57
V0
Number of terminals per level
2
Number of levels
1
Housing insulation material
Thermoplastic
Rated voltage
500 В
Rated current In
20 А
Closing plate can be fitted if required
Yes
Operating temperature
105 град.C
Operating temperature from
-40 град.C
Connection position
Side
Stranded wire cross-section with ferrule
0.14...4 мм²
Flexible stranded conductor cross-section up to
6 кв.мм
Stranded flexible conductor cross-section from
.14 кв.мм
Solid conductor cross-section to
6 кв.мм
Solid conductor cross-section from
.14 кв.мм
Cross-section of extra-fine-stranded flexible conductor without ferrule to
6 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
.14 кв.мм
With built-in test socket
No
Mounting method
DIN rail 35 mm
Electrical connection type 1
Screw connection
Electrical connection type 2
Screw connection
Colour
Grey
Color
Grey
Width/connection pitch
6.2 мм
