SMK terminal 4x2 pass-through branch 4 poles with mounting base (1 input 2 outputs per pole) Rexant 07-5247

REXANT reusable through branch terminals are designed for connecting stripped single-core and multi-core copper conductors. Consists of 4 insulated poles. Used to split a bundle of 4 pairs of wires into 2 directions. Contact is made by clamping the conductor with a plate. The design prevents accidental contact disconnection. A special technological hole on the terminal body is intended for checking the connection with a tester or multimeter probe. For ease of use, different phases of the terminal have unique color markings. Specifications: Material: Polyamide 66 Number of poles: 4 Number of inlets: 12 Contact material: tinned copper Clamp: steel Color: gray Voltage: 450 V Wire types: single-core, multi-core Current: for single-core wires — 32 A, for multi-core wires — 24 A Supported cross-section: 2x0.14-4 mm2 (single-core wire), 2x0.2-2.5 mm2 (multi-core wire) Operating temperature: –40...+85 °C Stripping length: 10 mm
