Volsten
Construction-mounting terminal SMK 5 pr. up to 4mm 32A 450 V 10pcs V02-9W-222-415 ser. Volsten 15221
SKU: 15221
ETIM: EC000897
27 ₽
Get back 1% in points
Analogues by specifications
No description available
Version tested for explosion protection "Ex e"
No
Internally linked levels
Yes
Minimum possible mounting height
14.5 мм
Length
12.7 мм
Number of terminals per level
5
Housing insulation material
Thermoplastic
Rated voltage
400 В
Rated current In
32 А
Closing plate can be fitted if required
No
Operating temperature
80 град.C
Operating temperature from
-20 град.C
Connection position
Side
Flexible stranded conductor cross-section up to
4 кв.мм
Stranded flexible conductor cross-section from
.08 кв.мм
Solid conductor cross-section to
2.5 кв.мм
Solid conductor cross-section from
.08 кв.мм
Mounting method
Direct mounting
Electrical connection type 1
Spring clamp connection
Color
Grey
Width/connection pitch
21 мм
