2,600 ₽
Get back 26 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 50 шт
Analogues by specifications
Stock by warehouse
No description available
Height
41.6 мм
Length
40.6 мм
Design
Three-phase installation
Flammability class of insulation material in accordance with UL57
V0
Climatic version
UKhL3
Number included
50
Number of terminals per pole
2
Number of poles
1
Maximum conductor cross-section
2.5 кв.мм
Clamping bracket material
Steel
Housing insulation material
Polyamide
Housing material
Polyamide
Housing material
Polyamide
Live part material
Brass
Minimum cross-section
1.0
Availability of PEN terminal
No
Rated impulse withstand voltage
6
Rated insulation voltage
1000
Rated AC operating voltage Ue
≤ 800
Rated DC operating voltage Ue
≤ 800
Rated frequency
50
Rated connection capacity
1...2.5
Rated voltage
800 В
Rated insulation voltage Ui
6000 В
Rated current In
24 А
Relative air humidity
≥ 90
Closing plate can be fitted if required
Yes
Operating temperature
110 град.C
Operating temperature from
-60...110 град.C
Connection position
Side (transverse)
Flame propagating
No
Repairability
No
Flexible stranded conductor cross-section up to
2.5 кв.мм
Stranded flexible conductor cross-section from
1...2.5 кв.мм
Solid conductor cross-section to
4 кв.мм
Solid conductor cross-section from
1...4 кв.мм
Mounting method
DIN rail (standard) 35 mm
Pollution degree
3
IP protection rating - without plug
IP00
Ingress protection (IP) with plug fitted
IP20
IP protection rating
IP00
Product/component type
KVI terminal
Electrical connection type 1
Screw connection
Electrical connection type 2
Screw connection
Colour
Black
Color
Black
Width
6.2 мм
Width/connection pitch
6.2 мм
