2,562 ₽
Get back 25 ₽ in points
Order multiple: 50 шт
Analogues by specifications
Stock by warehouse
No description available
Height
41.6 мм
Length
45.7 мм
Design
Neutral
Flammability class of insulation material in accordance with UL57
V0
Climatic version
UKhL3
Number included
50
Number of terminals per pole
2
Number of poles
1
Maximum conductor cross-section
6 кв.мм
Clamping bracket material
Steel
Housing insulation material
Polyamide
Housing material
Polyamide
Housing material
Polyamide
Live part material
Brass
Minimum cross-section
2.5
Availability of PEN terminal
No
Rated impulse withstand voltage
6
Rated insulation voltage
1000
Rated AC operating voltage Ue
≤ 800
Rated DC operating voltage Ue
≤ 800
Rated frequency
50
Rated connection capacity
2.5...6
Rated voltage
800 В
Rated insulation voltage Ui
6000 В
Rated current In
50 А
Relative air humidity
≥ 90
Closing plate can be fitted if required
Yes
Operating temperature
110 град.C
Operating temperature from
-60...110 град.C
Connection position
Side (transverse)
Flame propagating
No
Repairability
No
Flexible stranded conductor cross-section up to
6 кв.мм
Stranded flexible conductor cross-section from
2.5...6 кв.мм
Solid conductor cross-section to
10 кв.мм
Solid conductor cross-section from
2.5...10 кв.мм
Mounting method
DIN rail (standard) 35 mm
Pollution degree
3
IP protection rating - without plug
IP00
Ingress protection (IP) with plug fitted
IP20
IP protection rating
IP00
Product/component type
KVI terminal
Electrical connection type 1
Screw connection
Electrical connection type 2
Screw connection
Colour
Blue/light blue
Color
Blue/light blue
Width
8.2 мм
Width/connection pitch
8.2 мм
0
★★★★★
