433 ₽
Get back 4 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 8 шт
From our own stock you can buy 15 шт in any quantity. Above that — supply on order, in multiples of 8 шт.
Analogues by specifications
Stock by warehouse
Inlet power terminals are designed for connecting large-sized conductors from 6 to 240mm2 when organizing the entry and distribution of conductors inside electrical enclosures and switchboards. Used for connecting copper and aluminum conductors when installing industrial equipment.
Connection via clamps makes installation as simple and fast as possible. The durable polyamide enclosure features enhanced fire resistance.
Height
88 мм
Height
88 мм
Length
88 мм
Length
88 мм
Design
PEN grounding
Flammability class of insulation material in accordance with UL57
V0
Climatic version
UKhL3
Number included
8
Number of terminals per pole
2
Number of poles
1
Clamping bracket material
Aluminum
Housing insulation material
Polyamide
Housing material
Polyamide
Housing material
Polyamide
Live part material
Aluminum
Tightening torque Nm at conductor cross-section
20
Availability of PEN terminal
Yes
Rated AC operating voltage Ue
≤ 800
Rated DC operating voltage Ue
≤ 800
Rated frequency
50
Rated connection capacity
16...95
Rated voltage
800 В
Rated insulation voltage Ui
800 В
Rated current In
Cu: 245 / Al: 220 А
Closing plate can be fitted if required
No
Operating temperature
85 град.C
Operating temperature from
-40...85 град.C
Connection position
Side (transverse)
Flame propagating
No
Flexible stranded conductor cross-section up to
95 кв.мм
Stranded flexible conductor cross-section from
16...95 кв.мм
Solid conductor cross-section to
95 кв.мм
Solid conductor cross-section from
16...95 кв.мм
Mounting method
DIN rail / screw
IP protection rating
IP20
Electrical connection type 1
Screw connection
Electrical connection type 2
Screw connection
Colour
Yellow-green
Color
Yellow-green
Width
24.0 мм
Width/connection pitch
24.0 мм
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
