DKC
Earth terminal, screw clamp, 2 connection points, 4 sq.mm TUR-4-PE DKC
SKU: TUR-4-PE
ETIM: EC000901
167 ₽
Get back 1 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 40 шт
From our own stock you can buy 43 шт in any quantity. Above that — supply on order, in multiples of 40 шт.
Analogues by specifications
Stock by warehouse
Screw clamp grounding terminal is designed for connecting two conductors. Mounting on OMEGA DIN rail. Operating temperature from -40 to +105°C. Housing is made of PA 6.6 with flammability class V0 UL-94. Has electrical contact with the DIN rail.
Yellow-green color, 2 connection points, 4 mm2. 1 channel for pluggable jumpers. Dimensions (H×W×D) 47.5×53×6.2 mm.
Minimum possible mounting height
47.5 мм
Length
53 мм
Length
53 мм
Flammability class of insulation material in accordance with UL57
V0
Number of terminals per level
2
Number of levels
1
Housing insulation material
Thermoplastic
Availability of PEN terminal
No
Closing plate can be fitted if required
Yes
Operating temperature
105 град.C
Operating temperature from
-40 град.C
Connection position
Sideways
Stranded wire cross-section with ferrule
0.14...4 мм²
Flexible stranded conductor cross-section up to
6 кв.мм
Stranded flexible conductor cross-section from
.14 кв.мм
Solid conductor cross-section to
6 кв.мм
Solid conductor cross-section from
.14 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
0.14...6 кв.мм
Mounting method
DIN rail 35 mm
Electrical connection type 1
Screw connection
Electrical connection type 2
Screw connection
Color
Yellow-green
Colour
Green/yellow
Width/connection pitch
6.2 мм
