DKC
Detachable Polypropylene Terminal Block, 12 Poles, 2.5 sq.mm, 24A, White 43112PLSP DKC
SKU: 43112PLSP
ETIM: EC001284
569 ₽
Get back 5 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
Plug-type screw terminal blocks are used for reliable connection, joining, and disconnection of conductors in plug-type electrical circuits. The white dielectric housing is made of durable polypropylene with an operating temperature range from -20 to +85 °C. The screw clamp design features 12 sections with a rated voltage of up to 450 V, current up to 24 A, and a wire cross-section of 2.5 mm2.
Version tested for explosion protection "Ex e"
No
Minimum possible mounting height
15 мм
Length
95 мм
Length
95 мм
Flammability class of insulation material in accordance with UL57
EV004431
Number of terminals per pole
2
Number of poles
12
Housing insulation material
Polypropylene (PP)
Rated voltage
450 В
Rated current In
24 А
Closing plate can be fitted if required
No
Transparent
No
Operating temperature
85 град.C
Operating temperature from
-40 град.C
Connection position
Side
Flexible stranded conductor cross-section up to
2.5 кв.мм
Stranded flexible conductor cross-section from
2.5 кв.мм
Solid conductor cross-section to
2.5 кв.мм
Solid conductor cross-section from
2.5 кв.мм
Mounting method
Direct mounting
Electrical connection type 1
Screw connection
Electrical connection type 2
Plug connector
Color
White
Colour
White
Width/connection pitch
8 мм
