Emergency button "Mushroom" d40mm 1NO+1NC with latching and twist release EMAS B102EE

EMAS pushbuttons switch alarm, power, and control circuits with a rated AC voltage of 240V. Various color options allow for the most efficient layout of switchboards and panels. They are used in electrical panels, industrial equipment, and power supply facilities. Maximum functionality Easy installation Block contacts are equipped with a fire-resistant V0 PA6 housing Ability to attach an illumination block contact Plastic parts are made of polycarbonate Convenient and safe cable connection Minimal heating, maximum service life Any mounting position possible Mechanical life 500,000 operations (minimum value) Electrical life 100,000 operations (minimum value) Operating temperature -15C / +80 C Protection IP IP50 Operating frequency 1200/3000 operations per hour Rated voltage, Ue 240V AC Rated current, Ie 4A Rated insulation voltage, Ui 300V Rated impulse voltage, Uimp 2.5 kB Rated insulation resistance not less than 10 MOhm (at 500V DC) Contact material AgNI Dielectric strength Between body and contact -2000V AC: open contact -1500V AC Connecting cable cross-section 1.5 -2.5 sq.mm Standard UL 508, TS EN 60947-5-1, VDE0660
