Toggle switch (1NO+1NC) EMAS B102C

Toggle switch (1NO+1NC) B102C IP50. Maximum functionality and easy installation. Assembly is carried out on a Lego principle. Possibility of attaching a backlight contact block. Plastic parts are made of polycarbonate. Convenient and safe cable connection. Use of universal holders and standard nameplates. Any position during installation is possible. Mechanical service life 500,000 operations. Electrical service life 100,000 operations. Operating temperatures min./max. -5/+40 °C. IP 50 protection class. Ultimate repeatability of operations without load: 3000 operations per hour; full load: 1200 operations per hour. Rated voltage 250 V AC. Rated current 4 A. Switched power 1000 VA. Insulation resistance 10 MΩ (min. 500 V DC). Wire cross-section 1.5 - 2.5 mm².
