Waterproof button green (1NC+1NO) EMAS KB14RY

EMAS pushbuttons switch signaling, power, and control circuits with a rated AC voltage of 240V. Various color options allow for the most efficient assembly of switchboards and panels. Used in electrical switchboards, industrial equipment, and power supply facilities. Maximum functionality Easy installation Block contacts are equipped with fire-resistant V0 PA6 housing Ability to connect an illumination block-contact Plastic parts are made of isolcarbate Convenient and safe cable connection Minimum heating, maximum service life Any installation position possible Mechanical life: 500,000 operations (minimum value) Electrical life: 100,000 operations (minimum value) Operating temperature: -5C / +40 C IP Rating: IP65 Operating frequency: 1200/3000 operations per hour Rated voltage, Ue: 240V AC Rated current, Ie: 4A Rated insulation voltage, Ui: 300V Rated impulse voltage, Uimp: 2.5 kV Rated insulation resistance: not less than 10 MOhm (at 500V DC) Contact material: AgNi Dielectric strength: Between body and contact -2000V AC; open contact -1500V AC Cross-section of connecting cable: 1.5 - 2.5 sq.mm Standard: UL 508, TS EN 60947-5-1, VDE0660
