IEK
ARMAFIX Spring-cage Push-in Terminal CP 2.5mm2 grey IEK YCT20-00-K03-002
SKU: YCT20-00-K03-002
ETIM: EC000897
6,100 ₽
Get back 61 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 100 шт
Analogues by specifications
Stock by warehouse
CP series Push-In terminal blocks have a special connection system that allows connecting wires without tools.
Cables with ferrules and single-core wires can be connected directly into the terminal for connections.
The button must be pressed to use flexible cable without ferrules for connection.
Potential equalization of these terminal blocks can be performed using jumpers available in various pole configurations.
Length
49.70 мм
Length
49.70 мм
Number of terminals per level
2
Number of poles
1
Number of levels
1
Housing insulation material
Other
Housing material
Polyamide 6.6
Housing material
Polyamide 6.6
Rated voltage
1000 В
Rated current In
24 А
Closing plate can be fitted if required
Yes
Operating temperature
85 град.C
Operating temperature from
-40...85 град.C
Connection position
Top
Flexible stranded conductor cross-section up to
2.5 кв.мм
Stranded flexible conductor cross-section from
0.2...2.5 кв.мм
Solid conductor cross-section to
4 кв.мм
Solid conductor cross-section from
0.2...4 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
0.2...2.5 кв.мм
Mounting method
DIN rail (standard) 35 mm
Electrical connection type 1
Spring clamp connection
Electrical connection type 2
Spring clamp connection
Colour
Grey
Color
Grey
Width/connection pitch
5.0 мм
