IEK
ARMAFIX screw terminal CTS-ML-PEN ground 2-level 4mm2 IEK YCT13-03-2-K52-004
SKU: YCT13-03-2-K52-004
ETIM: EC000901
34,558 ₽
Get back 345 ₽ in points
Order multiple: 100 шт
Analogues by specifications
Stock by warehouse
CTS series screw clamp terminal blocks are used in various industrial, energy, and infrastructure solutions. They feature a universal clamping system with high contact force.
CTS-MC terminal blocks are used to connect multiple wires in a single terminal block, thereby eliminating reliability issues that arise when connecting multiple wires into a single clamp.
The grounding terminal allows for connecting grounding wires and is available in the standard green-yellow color.
Minimum possible mounting height
59.5 мм
Length
57 мм
Length
57 мм
Number of terminals per level
1
Number of levels
2
Housing insulation material
Thermoplastic
Availability of PEN terminal
Yes
Rated insulation voltage Ui
800 В
Closing plate can be fitted if required
Yes
Operating temperature
85 град.C
Operating temperature from
-40...85 град.C
Connection position
Side (transverse)
Stranded wire cross-section with ferrule
0.2...4 мм²
Flexible stranded conductor cross-section up to
4 кв.мм
Stranded flexible conductor cross-section from
0.2...4 кв.мм
Solid conductor cross-section to
6 кв.мм
Solid conductor cross-section from
0.2...6 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
0.2...4 кв.мм
Mounting method
DIN rail (standard) 35 mm
Electrical connection type 1
Screw connection
Electrical connection type 2
Screw connection
Colour
Yellow-green
Color
Yellow-green
Width/connection pitch
6 мм
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
