Terminal block Polystrol white 2.5-16 (25) mm2 60A 12 sections EKF plc-KK-25-60-ps-w
SKU: plc-KK-25-60-ps-w
ETIM: EC001284
1,370 ₽
Get back 13 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 10 шт
Analogues by specifications
Stock by warehouse
Terminal blocks (terminal clamp, 12 sections) EKF PROxima are made of white polyethylene and non-flammable polystyrene. Used in electrical circuits with a rated voltage of up to 400V and a frequency of 50 Hz. Designed for screw connection of conductors, eliminating the possibility of a short circuit to the electrical installation ground. The block is easily cut into blocks with the required number of terminal pairs. Used in AC electrical circuits with a rated voltage of up to 400 V and a frequency of 50 Hz. Available in white, black, blue, and yellow colors.
Version tested for explosion protection "Ex e"
No
Minimum possible mounting height
25 мм
Length
189 мм
Length
189 мм
Flammability class of insulation material in accordance with UL57
V0
Number of terminals per pole
2
Number of poles
12
Housing insulation material
Polypropylene (PP)
Rated voltage
400 В
Rated current In
60 А
Closing plate can be fitted if required
No
Transparent
No
Operating temperature
80 град.C
Operating temperature from
-25...80 град.C
Connection position
Side
Hole centre distance
16 мм
Flexible stranded conductor cross-section up to
25 кв.мм
Stranded flexible conductor cross-section from
25...25 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
25...25 кв.мм
Mounting method
Direct mounting
Electrical connection type 1
Screw connection
Electrical connection type 2
Screw connection
Colour
White
Color
White
Width/connection pitch
16 мм
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
Related products
1501 ₽
NAVIGATOR Screw terminal block ceramic KZV 61 710 NTB-HCR-3-24/WH (pack 20pcs) Navigator 61710
SKU: 61710
1370 ₽
IEK Screw clamp ZVI-100 n/g 10-25mm2 12pairs black IEK UZV5-100-25
SKU: UZV5-100-25
171 ₽
Klemsan DIN-rail terminal block 6mm2 yellow AVK6(RP) Klemsan 304143RP
SKU: 304143RP
677 ₽
IEK Power input terminal KVS 35-150mm2 grey IEK YZN12-150-K03
