Rexant
Screw terminal block KV-6 2.5-6mm2 6A (ZVI) polypropylene black (pkg. 1pc) Rexant 07-5006-2-01
SKU: 07-5006-2-01
ETIM: EC001284
131 ₽
Get back 1 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Terminal block KV-6 6 A, 6 mm2, PP (polypropylene), black REXANT is designed to create an insulated pass-through connection for stranded and solid cables and wires. Using a terminal block during electrical installation work will significantly save installation time and ensure a safe and reliable connection between conductors. The connection is made using copper contacts. The block housing is made of polypropylene, which extends the operating temperature range up to +95 °C. Cables and wires are secured with a screw clamp.
Technical characteristics:
Housing material: polypropylene
Cross-section of connected cores: 2.5-6 mm2
Maximum current: 6 A
Operating temperature: -10…+95 °C
Housing color: black
Version tested for explosion protection "Ex e"
No
Number of terminals per pole
2
Number of poles
12
Housing insulation material
Polyethylene
Rated current In
6 А
Operating temperature
95 град.C
Operating temperature from
-10 град.C
Connection position
Side
Flexible stranded conductor cross-section up to
6 кв.мм
Stranded flexible conductor cross-section from
2.5 кв.мм
Mounting method
Direct mounting
Electrical connection type 1
Screw connection
Electrical connection type 2
Screw connection
Color
Black
