Generica (Группа IEK)
Terminal block ZVI-5 1.5-sq.mm 12pair GENERICA UZV10-005-004-K01-10-G
SKU: UZV10-005-004-K01-10-G
ETIM: EC001284
47 ₽
Get back 1% in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
ZVI type screw contact terminal, trademark GENERICA, is designed for the electrical and mechanical connection of single-core and pre-prepared multi-core copper conductors with a cross-section from 1.5 to 4 mm2 in AC and DC circuits.
Height
12.6 мм
Mechanical design group
M3
Length
108 мм
Length
108 мм
Permissible continuous current
5
Number included
13
Number of terminals per pole
3
Number of terminal pairs
12
Number of poles
12
Max. operational voltage Ue
451
Maximum conductor cross-section
4 кв.мм
Clamping bracket material
Brass
Housing insulation material
Polyethylene
Housing material
Polyethylene
Live part material
Brass
Tightening torque Nm at conductor cross-section
0.6
Rated AC operating voltage Ue
450
Rated connection capacity
1.5...4
Rated voltage
450 В
Rated current In
5 А
Transparent
Yes
Operating temperature
85 град.C
Operating temperature from
-25...85 град.C
Connection position
Side (transverse)
Repairability
No
Flexible stranded conductor cross-section up to
4 кв.мм
Stranded flexible conductor cross-section from
1.5...4 кв.мм
Solid conductor cross-section to
4 кв.мм
Solid conductor cross-section from
1.5...4 кв.мм
Mounting method
Direct mounting
IP protection rating
IP20
Product/component type
ZVI terminal block
Electrical connection type 1
Screw connection
Electrical connection type 2
Screw connection
Colour
Grey/white
Color
Grey/White
Width
15.4 мм
Width/connection pitch
15.4 мм
