Signal column 70mm LED strobe 220V alum. wall-mounted connection 100mm with buzzer red EMAS IK71F220ZD01

Signal column 70mm, single color (red), with buzzer, FLESH strobe, 100mm aluminum tube with wall mount, 220V AC, IP40 TECHNICAL INFORMATION Sound module (buzzer) 90dB Lamp type LED (FLESH) Operating frequency 50Hz Operating voltage 220V AC Column diameter 70mm. Power consumption 4W Insulation voltage (Ui) 300V Operating temperature -25 °C / + 70 °C Protection class IP40 Cable connection cross-section 0.75-1.5mm2 Clamping force 1.8 N Socket type BA15S IK Series Electrical life (min. hours) 10,000 hours EMAS signal columns are used for light and sound-light signaling of equipment status, providing permissive or prohibitive light signals, and warning personnel of emergency and extraordinary situations related to safe equipment operation. The range includes signal columns with incandescent bulbs, LED lamps, and LED strobe lamps (flashing). Light-signal columns have a modular design, are installed without tools, and provide continuous information on current operating modes, malfunctions, and possible critical states. The signal column can be equipped with an acoustic signaling device (buzzer) 90 dB. Advantages of signal fittings: • Heat resistant • Two types of outer diameter 50mm - 70mm • Polycarbonate lens • Convenient connection methods • Various supply voltages • Housing is resistant to mechanical impacts • Buzzer option
