Adapter kit RIX-10-70/300 92307 KBT

• Designed for the insulation and sealing of T-shaped connections of end sleeves in gas-insulated switchgear cells with threaded bushing type "C" complying with CENELEC-EN 50181 or DIN 47636 • Kit contents: • adapter body • threaded stud • flat washer • spring washer • nut • silicone paste • Resistant to tracking and weather conditions • The adapter insulation is made of thick-walled silicone elastomer • Color: brick red • Operating voltage: up to 10 kV inclusive • Maximum current load: 630 A • Due to the special elastomer used for the body, combined with the structural feature of the internal part, the adapter has a very wide range of applicability for cable cross-sections, regardless of the cable insulation type: paper-oil-impregnated or cross-linked polyethylene insulation. • Adapters are designed for use in conjunction with "KVT" heat-shrinkable end cable sleeves equipped with bolt terminals for single-core and three-core cables with paper-oil-impregnated and cross-linked polyethylene insulation • Adapters can be used together with Raychem heat-shrinkable end sleeves and their analogs • The "KVT" bolt terminal is connected to the bushing with a threaded stud and a nut • Threaded stud M16/ M16 • An insulated threaded plug is used to seal the back of the adapter • Quick installation and disassembly with the possibility of reuse • The use of cable adapters allows for the connection of different types of cables to the same compact switchgear • Adapters allow for reducing the phase-to-phase air gap to ensure the normal functioning of the equipment • Adapters are supplied in a kit that includes materials for 3 phases • No special tools or flame-related work are required to install the adapter onto a mounted cable end sleeve
