Support structure for horizontal rectangular air ducts and metal cable tray systems TECHNORAPTOR FOOT 2000x1500 KM-TR-F-SSHRAD-2000-1500 KM TR0097 SISTEMA KM

The specified dimensions are maximum. The frame is adjustable depending on the connection dimensions of the equipment being installed. Before ordering components, it is necessary to calculate the snow and wind load for the specific delivery object. It is prohibited to fasten roof supports to the base. Fastening elements of the unit (bolts, nuts, vibration dampers, etc.) are not included in the specification of the support structure; the quantity and dimensions depend on the specific equipment. The KM-TECHNORAPTOR-FOOT roof support provides compensation for roof slope up to 8 degrees. Maximum allowable distributed load on the metal frame is 160 kg. This structure is made of steel strat-profile with a Sendzimir galvanized coating. It is also possible to have the profile coated using the hot-dip galvanizing method.
