TECHNORAPTOR FOOT 1500x3500 KM-TR-F-SSEI-1500-3500 KM TR0035 SYSTEM KM support structure for equipment installation

The specified dimensions are maximum. The frame is adjustable depending on the connection dimensions of the installed equipment. Before ordering components, it is required to calculate the snow and wind load for the specific delivery object. It is prohibited to fasten roof supports to the base. The unit's fasteners (bolts, nuts, vibration dampers, etc.) are not included in the support structure specification; the quantity and sizes depend on the specific equipment. The KM-TECHNORAPTOR-FOOT roof support provides compensation for roof slope up to 8 degrees. The maximum allowable distributed load on the metal frame is 640 kg. This structure is made of steel strat-profile with a galvanized coating applied by the Sendzimir method. It is also possible to have a version with a hot-dip galvanized profile coating.
