IEK
Combined contact AKDKm-800e (AKDKm-40) MASTER electronic trip IEK SVA71D-AK-DK-02
SKU: SVA71D-AK-DK-02
ETIM: EC001286
19,776 ₽
Get back 197 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 6 шт
Analogues by specifications
Stock by warehouse
No description available
Height
50.0 мм
Height
50.0 мм
Depth
40.0 мм
Operating voltage range
400V
Operating voltage range
400
Operating temperature range
-40...60
Number of normally closed contacts (NC)
0
Number of normally closed (NC) contacts
0
Number of normally open contacts (NO)
0
Number of normally open (NO) contacts
0
Number of fault signal switches
1
Number of switching contacts
2
Number of changeover contacts
2
Maximum conductor cross-section
0.2 кв.мм
Rated operating current at AC 230V for AC
1
Rated operational current at AC 230 V for DK
1
Rated operating current at AC 400 V for AC
1
Rated operational current at AC 400 V for DK
1
Rated operational current at DC 220 V for AK
0.2
Rated operating current at DC 220 V for aux. contacts
0.2
Rated voltage
400 В
Rated switching current
1 А
Suitable for maximum current of main contact block
800 А
Included with delivery
No
Operating mode
Continuous
Current type
Alternating current (AC)
Switch-on current type
Alternating current (AC)
Type of control voltage current
Alternating current (AC)
With automatic leakage current self-test
No
Compatibility with circuit breaker
VA88-40 Master with electronic release
Mounting method
Other
IP protection rating
IP20
Connection side to circuit breaker
Left
Design type
Plug-in
Equipment type
Auxiliary contact/signal contact
Connection type
Screw connection
Conventional thermal current
3
Device installation on
Circuit breaker
Frequency (Hz)
50/60 Hz
Width
50.0 мм
Width (TE)
40
