EKF
Contactor KME compact 25A 24V 1NO EKF PROxima ctr-s-25-24
SKU: ctr-s-25-24
ETIM: EC000066
2378 ₽
Price list (incl. VAT):
3273 ₽
Available August 11
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
| Manufacturer warehouse | |||||
|
Manufacturer warehouse
Available
|
124 | шт | August 11 | clarifying | |
Select a warehouse to order
No description available
| Number of auxiliary NO contacts | 1 |
| Number of auxiliary break contacts | 0 |
| Number of main NO contacts | 3 |
| Number of main NC contacts | 0 |
| Modular design | No |
| Rated switching power at AC-4, 400 V | 4 кВт |
| Rated operational current Ie at AC-4, 400 V | 9 А |
| Rated power at AC-3, 400 V | 11 кВт |
| Rated operational power (NEMA) | 6 кВт |
| Rated control supply voltage Us AC at 50 Hz up to | 26.4 В |
| Rated control supply voltage Us AC at 50 Hz from | 19.2...26.4 В |
| Rated control supply voltage Us DC up to | 0 В |
| Rated control supply voltage Us DC from | 0 В |
| Rated operational current Ie at AC-1, 400 V | 43 А |
| Rated operating current Ie at AC-3, 400 V | 25 А |
| Switch-on current type | AC (alternating) |
| Main electrical circuit connection type | Screw connection |
