1,925 ₽
Get back 19 ₽ in points
Analogues by specifications
Stock by warehouse
KME EKF PROxima contactors consist of a housing, fixed contacts secured within it, and moving contacts secured in the moving part of the magnetic system. The stationary part of the magnetic system is rigidly fixed in the KME housing. A spring prevents the contacts from closing. When voltage is applied to the control coil, a magnetic field arises in the contactor's magnetic system, which, overcoming the spring resistance, closes the magnetic system and closes the contacts. When voltage is removed from the control coil, the spring opens the contacts. Commutation with aluminum and copper wire is possible.
The main purpose of the KME contactor is frequent remote switching of power electric circuits in normal operating mode.
Number of auxiliary NO contacts
1
Number of auxiliary break contacts
1
Number of main NO contacts
3
Number of main NC contacts
0
Modular design
No
Rated switching power at AC-4, 400 V
9 кВт
Rated operational current Ie at AC-4, 400 V
18 А
Rated power at AC-3, 400 V
18 кВт
Rated operational power (NEMA)
10 кВт
Rated control supply voltage Us AC at 50 Hz up to
440 В
Rated control supply voltage Us AC at 50 Hz from
340...440 В
Rated control supply voltage Us DC up to
0 В
Rated control supply voltage Us DC from
0 В
Rated operational current Ie at AC-1, 400 V
60 А
Rated operating current Ie at AC-3, 400 V
40 А
Switch-on current type
AC (alternating)
Main electrical circuit connection type
Screw connection
