Systeme Electric
Contactor MC1D 3p 18A cat. 110V DC 1NO+1NC SE MC1D18FD Systeme Electric
SKU: MC1D18FD
ETIM: EC000066
13,085 ₽
Get back 130 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
SystemePact MC1D series contactor with rated current 18 A, 3P, 1NO+1NC; control voltage – 110 V DC; mounting – on DIN rail or mounting plate. SystemePact MC1D series contactors are designed for controlling various types of motors, as well as pumps, elevators, and ventilation systems. They have increased electrical and mechanical life; can be equipped with auxiliary contacts, thermal relays, mechanical interlocks, surge suppressors (formerly Schneider Electric TeSys LC1D, TeSys LC1D18FD, LC1D18FL).
Number of auxiliary NO contacts
1
Number of auxiliary break contacts
1
Number of main NO contacts
3
Number of main NC contacts
0
Modular design
No
Control coil voltage
110 В
Rated control supply voltage Us DC up to
110 В
Rated control supply voltage Us DC from
110 В
Rated operational current Ie at AC-1, 400 V
32 А
Rated operating current Ie at AC-3, 400 V
18 А
Switch-on current type
Direct current (DC)
Product/component type
Contactor
