EKF
Modular contactor KM 100A 2NO+2NC 230V AC (6 mod.) AVERES EKF km-av-6-100-22-230V
SKU: km-av-6-100-22-230V
ETIM: EC001653
26,765 ₽
Get back 267 ₽ in points
Analogues by specifications
Stock by warehouse
KM Averes modular contactors are high-quality equipment designed for efficient control and switching in electrical circuits used in lighting, heating systems, as well as for controlling the operation of electric motors and pumping equipment. They are designed taking into account the needs of modern industrial and domestic applications and feature the ability to operate with various control voltage levels — 24, 48, 110, and 230 V, ensuring wide adaptability to various power systems.
The KM Averes series offers contactors with a rated current range from 20 to 125 amps for operation in AC-1 and AC-3 (AC-7a; AC-7b) categories. This choice allows for precise adjustment of the contactor to specified electrical load parameters, ensuring reliability and efficiency in any system.
Additional equipment possible
Yes
Mounting installation depth
50 мм
Utilization category
1
Number of main NO contacts
2
Number of modules
6
Number of normally closed (NC) contacts
2
Number of normally open (NO) contacts
2
Number of main NC contacts
2
Material
Plastic
Rated power at AC-3, 400 V
22 кВт
Rated control supply voltage Us AC at 50 Hz up to
230 В
Rated control supply voltage Us AC at 50 Hz from
230...230 В
Rated control circuit AC supply voltage Us at 60 Hz to
230 В
Rated control circuit AC supply voltage Us at 60 Hz from
230...230 В
Rated voltage at
400 В
Rated voltage from
230...400 В
Rated control circuit voltage to
253 В
Rated control circuit voltage from
184...253 В
Rated operational current
100 А
Rated operational current Ie at AC-1, 400 V
65 А
Rated operating current Ie at AC-3, 400 V
22 А
Slider for manual switch
No
Switch-on current type
AC (alternating)
Control circuit voltage current type
AC (alternating)
Operating voltage current type
AC (alternating)
IP protection rating
IP20
Main electrical circuit connection type
Screw connection
Width in modular units
6
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
