Modular contactor KM 25A 2NC 230V AC (1 module) AVERES EKF km-av-1-25-02-230V
SKU: km-av-1-25-02-230V
ETIM: EC001653
6874 ₽
Price list (incl. VAT):
6709 ₽
Available August 11
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
| Manufacturer warehouse | |||||
|
Manufacturer warehouse
Available
|
26 | шт | August 11 | clarifying | |
Select a warehouse to order
KM Averes modular contactors are high-quality equipment designed for efficient control and switching in electrical circuits used in lighting, heating systems, as well as for controlling the operation of electric motors and pumping equipment. They are designed taking into account the needs of modern industrial and domestic applications and feature the ability to operate with various control voltage levels — 24, 48, 110, and 230 V, ensuring wide adaptability to various power systems.
The KM Averes series offers contactors with a rated current range from 20 to 125 amps for operation in AC-1 and AC-3 (AC-7a; AC-7b) categories. This choice allows for precise adjustment of the contactor to specified electrical load parameters, ensuring reliability and efficiency in any system.
| Additional equipment possible | Yes |
| Mounting installation depth | 50 мм |
| Utilization category | 1 |
| Number of main NO contacts | 0 |
| Number of modules | 1 |
| Number of normally closed (NC) contacts | 2 |
| Number of normally open (NO) contacts | 0 |
| Number of main NC contacts | 2 |
| Material | Plastic |
| Rated control supply voltage Us AC at 50 Hz up to | 230 В |
| Rated control supply voltage Us AC at 50 Hz from | 230...230 В |
| Rated control circuit AC supply voltage Us at 60 Hz to | 230 В |
| Rated control circuit AC supply voltage Us at 60 Hz from | 230...230 В |
| Rated voltage at | 400 В |
| Rated voltage from | 230...400 В |
| Rated control circuit voltage to | 253 В |
| Rated control circuit voltage from | 184...253 В |
| Rated operational current | 25 А |
| Rated operational current Ie at AC-1, 400 V | 1 А |
| Rated operating current Ie at AC-3, 400 V | 25 А |
| Slider for manual switch | No |
| Switch-on current type | AC (alternating) |
| Control circuit voltage current type | AC (alternating) |
| Operating voltage current type | AC (alternating) |
| IP protection rating | IP20 |
| Main electrical circuit connection type | Screw connection |
| Width in modular units | 1 |
