Modular Contactor MK-103 3NO+1NC 32A 230V DEKraft 18075DEK
SKU: 18075DEK
ETIM: EC001653
4903 ₽
Preorder
Modular contactor MK-103 Dekraft; rated current 32 A (AC-7a); number and configuration of contacts – 3NO+1NC; control voltage 220 V AC; width – 3 mod. x 18 mm; mounting – DIN rail. MK-103 contactors are used in networks with voltage up to 400 V AC for remote control of small loads requiring a large number of switching operations, such as pumps, ventilation systems, etc. Modular contactors do not require additional settings or special maintenance.
| Additional equipment possible | Yes |
| Mounting installation depth | 68 мм |
| Number of auxiliary NO contacts | 0 |
| Number of auxiliary break contacts | 0 |
| Number of main NO contacts | 3 |
| Number of modules | 3 |
| Number of normally closed contacts (NC) | 1 |
| Number of normally closed (NC) contacts | 1 |
| Number of normally open contacts (NO) | 3 |
| Number of normally open (NO) contacts | 3 |
| Number of main NC contacts | 1 |
| Rated power at AC-3, 400 V | 1.9 кВт |
| Rated control supply voltage Us AC at 50 Hz up to | 230 В |
| Rated control supply voltage Us AC at 50 Hz from | 220 В |
| Rated control circuit AC supply voltage Us at 60 Hz to | 230 В |
| Rated control circuit AC supply voltage Us at 60 Hz from | 220 В |
| Rated voltage at | 400 В |
| Rated voltage from | 400 В |
| Rated control circuit voltage to | 230 В |
| Rated control circuit voltage from | 220 В |
| Rated operational current | 32 А |
| Rated operational current Ie at AC-1, 400 V | 6.5 А |
| Rated operating current Ie at AC-3, 400 V | 25 А |
| Slider for manual switch | No |
| Control circuit voltage current type | Alternating current (AC) |
| Operating voltage current type | Alternating current (AC) |
| IP protection rating | IP20 |
| Width in modular units | 3 |
