Limit Switch with Two Contacts, Normally Open + Normally Closed (NO+NC), with Roller RAM block R5MC103 DKC
SKU: R5MC103
ETIM: EC000030
1,076 ₽
Get back 10 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
Limit switch with NO+NC contacts is designed for switching the lighting system in enclosure equipment. Made of durable black plastic with IP65 protection rating. Equipped with a roller mechanism and two types of contacts - normally open NO and normally closed NC. Screw mounting type and M20 cable entry ensure convenient and reliable installation.
Without self-return (with latching)
No
Control element alignment
Roller cam straight
Interface version
No (without)
Gas explosion protection category (EU ATEX directives)
No (without)
Dust explosion protection category (EU ATEX Directive)
No (without)
Number of normally closed (NC) contacts
1
Number of normally open (NO) contacts
1
Housing design
Cuboid
Housing complies with standards
Other
Housing material
Plastic
Housing material
Plastic
Rated operational current Ie at AC-15, 125 V
5 А
Rated operational current Ie at AC-15, 230V
5 А
Rated operational current Ie at AC-15, 24 V
5 А
Rated operating current Ie at DC-13, 125 V
.4 А
Rated operating current Ie at DC-13, 230 V
.2 А
Rated operating current Ie at DC-13, 24 V
5 А
Suitable for security systems
Yes
Interface protocol for safety communication
None
Ambient operating temperature to
70 град.C
Ambient operating temperature from
-10 град.C
Manual control
No
With status indication
No
IP protection rating
IP65
Connection type
Metric cable gland
Control element type
Pusher with roller
Switching function
Quick-break switch
Electronic output
No
