1,817 ₽
Analogues by specifications
No description available
Without self-return (with latching)
No
Control element alignment
Other
Interface version
No (without)
Gas explosion protection category (EU ATEX directives)
No (without)
Dust explosion protection category (EU ATEX Directive)
No (without)
Number of normally closed (NC) contacts
1
Number of normally open (NO) contacts
1
Number of switching contacts
0
Number of safety-related auxiliary contacts
0
Housing material
Metal
Housing material
Metal
Rated operational current Ie at AC-15, 125 V
10 А
Rated operational current Ie at AC-15, 230V
5 А
Rated operational current Ie at AC-15, 24 V
10 А
Rated operating current Ie at DC-13, 125 V
0.5 А
Rated operating current Ie at DC-13, 230 V
0.3 А
Rated operating current Ie at DC-13, 24 V
8 А
Suitable for security systems
No
Housing coating
No (without)
Interface protocol for safety communication
No (without)
Ambient operating temperature to
80 град.C
Ambient operating temperature from
-10...80 град.C
Manual control
No
With status indication
No
IP protection rating
IP66
Connection type
Clamp/Screw mounting
Control element type
Adjustable swivel lever
Electronic output
No
0
★★★★★
