Pull box U-995 150x150x100mm IP54 with seal metal black Y-995-150-150-100-54 Era B0062810
SKU: Б0062810
ETIM: EC002600
Price on request
Analogues by specifications
Stock by warehouse
Era metal pull box is a steel body without seams or soldering, designed for the placement and protection of connections and branches of wires and cables with voltage up to 1000V. Boxes are available in versions for concealed and open installation. The body with a specialized primer coating is resistant to corrosion (coating thickness 20-70 μm) and can subsequently be painted in the required color. We offer versions of boxes with a seal - IP54 protection rating and without - IP31 protection rating. The lid is attached with four self-tapping screws, ensuring its reliable fixation.
Rear entry
No
Explosion-proof verified
No
Housing entry type
No (without)
All-weather
No
Depth
100 мм
Length
150 мм
For gas explosion hazardous areas
No (without)
For dust explosion protection zone (EU ATEX directives)
No (without)
For installation in ground
No
For underwater installation
No
Protective surface coating
Varnished
Material
Steel
Halogen-free
Yes
Rated insulation voltage Ui
230 В
Equipment
No (without)
Sealable
No
Transparent cover
No
With protective shield
No
Joinable in a row
No
Mounting method
Wall/Ceiling
IP protection rating
IP54
Operating temperature to
40 град.C
Operating temperature from
-25 град.C
Cover type
Mounting cover
Cover fixing
Screw
Shape
Square
Color
Black
Width
150 мм
