5,986 ₽
Get back 59 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Heat Box 200 200 x 150 x 75 mm junction box is designed for connection to the power distribution network of heating cables, temperature sensors, as well as for switching power and information cables in normal operating areas.
The housing design provides IP65 protection against the penetration of moisture and dust and high corrosion resistance.
The housing and lid are made of polycarbonate and are secured to each other with stainless steel screws. Dust and moisture protection is provided by a neoprene gasket. The junction boxes are equipped with two M20 and one M25 polyamide cable entries with IP68 protection rating. Unused holes are closed with plugs of the corresponding diameter (included in the kit). The material of the plugs is polyamide.
Rear entry
No
Explosion-proof verified
No
Housing entry type
Stepped membrane gland
All-weather
Yes
Depth
79 мм
Length
140 мм
Length
200 мм
For gas explosion hazardous areas
1, 2
For dust explosion protection zone (EU ATEX directives)
No (without)
For installation in ground
No
For underwater installation
No
Protective surface coating
Other
Design
Junction box
Number of inputs, entries
12
Cast
Yes
Material
Plastic
Rated insulation voltage Ui
450 В
Circuit integrity fire resistance (per DIN 4102-12)
No (without)
Equipment
Terminal
Sealable
No
Transparent cover
No
Joinable in a row
Yes
Mounting method
Universal
IP protection rating
IP66
Operating temperature to
80 град.C
Operating temperature from
-40...+80 град.C
Cover type
Mounting cover
Cover fixing
Screw
Shape
Square
Color
White
Colour
White
Width
140 мм
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
