DKC
Steel box FS with cable entries and terminals, IP55, 150x150x80 mm, 6p, 450V, 6A, 4 mm2 FSB31604 DKC
SKU: FSB31604
ETIM: EC002600
7,609 ₽
Get back 76 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
The purpose of fire-resistant junction boxes is the connection and branching of wires and cables while maintaining functionality during a fire. The boxes are used as part of fire-resistant cable lines and have undergone testing in accordance with GOST R 53316 with products from various cable plants.
Material – steel, color – orange, RAL2003. The delivery set of the boxes includes ceramic terminal blocks, as well as fire-resistant fasteners (mounting plate, anchors, screws, washers, nuts).
Rear entry
Yes
Explosion-proof verified
No
Housing entry type
Stepped membrane gland
All-weather
Yes
Depth
80 mm
Length
150 mm
Length
150 mm
For gas explosion hazardous areas
No (without)
For dust explosion protection zone (EU ATEX directives)
No (without)
Protective surface coating
Untreated
Number of inputs, entries
6
Maximum conductor cross-section
4 mm²
Material
Steel
Halogen-free
Yes
Rated insulation voltage Ui
450 V
Circuit integrity fire resistance (per DIN 4102-12)
No (without)
Equipment
Mounting plate/board
Sealable
Yes
With protective shield
No
Joinable in a row
Yes
Mounting method
Universal
IP protection rating
IP55
Operating temperature to
40 °C
Operating temperature to
40 °C
Operating temperature from
-60 °C
Operating temperature from
-60 °C
Cover fixing
Screw
Shape
Rectangle
Color
Orange
Colour
Orange
Width
150 mm
