Distribution board enclosure 400x500x190mm polyester Cetinkaya Pano CP531

CP 531 polyester industrial enclosures by Cetinkaya Pano are made of SMC material — thermosetting polyester resins reinforced with glass fiber, and are characterized by increased strength. They do not require grounding, are resistant to UV radiation, non-flammable, and have a wide operating temperature range (from -25 to + 60°C). Improvement of quality and consumer properties of the polyester enclosure: Vandal resistance: enclosures have the highest protection degree IK 8 (impact energy 20 J or a 5 kg weight drop from a height of 40 cm). Non-flammability: the temperature at which the enclosure self-extinguishes exceeds 1000°C. Corrosion resistance: enclosures do not rust and do not require painting. Wide operating temperature range: operating temperature from -50°C to +70°C. No need for enclosure grounding: due to the dielectric properties of the material, enclosures do not require grounding. UV resistance: SMC material properties make the enclosures resistant to UV rays, allowing for outdoor installation. Compatibility with AMR systems: SMC material does not interfere with radio and GSM signal transmission. CHARACTERISTICS Brand - Cetinkaya Pano Mounting type – Wall or floor mounting possible Main material - Polyester Operating temperature from -25 to + 60 °C Protection degree (IP) - IP 54 Width - 400 mm Height - 500 mm Depth - 190 mm Packaging - 1 piece, individual packaging Color palette - RAL 7035 Din-modules - 30 M (2x15) Din-rail - Yes Product type - Polyester enclosure Halogen - no Door with lock Hinged door opening more than 90 degrees Made of glass-fiber reinforced polyester Gasket seal – Thermoplastic insulating material Fire resistance - more than 650 °C Country of manufacture - Turkey
