221 ₽
Analogues by specifications
SKL 12A-K-2-220 lamp – light signaling device.
It is an indicator lamp of normal brightness (15 MKD), with a built-in LED, high flat light-diffusing red colored lens, and a plastic body and ring. IP54. Bipolar (AC of arbitrary frequency and shape or DC of any direction). It is an analog to imported light signaling devices (Schneider Electric, ABB, etc.) with an installation diameter of 22 mm.
Designed for installation on electrical panel boards, control panels, and other electrical equipment. Connection is made via lamellas for soldering.
Supplied with lamp
Yes
External part height
15 мм
Lens design
High
Number of light indicators
1
Lens design
Round
Front ring material
Plastic
Rated operating voltage Ue up to
240 В
Rated operating voltage Ue from
170 В
Current type
AC/DC
IP protection rating
IP54
Connection type
Solder tab connection
Lens color
Red
Front ring colour
White
