LED strip MICROLED-PW-M288-10mm 24V Day 4000K 12W/m IP66 2216 waterproof (pack 5m) Arlight 046751
SKU: 046751
ETIM: EC002706
9577 ₽
Preorder
MICROLED M288 series waterproof LED strip, IP66 (PW - matte silicone tube). SMD 2216 LEDs, 288 pcs/m, white board 8 mm wide, 3M tape. Color DAYLIGHT 4000K, color rendering index CRI>90, angle 170°. Power 24 V, power consumption 12 W/m (60 W per 5 m). Dimensions 5000x10x5 mm. Min. segment 27.7 mm, 8 LEDs. Price per 1 m.
| Height | 5 мм |
| Height/depth | 5 мм |
| Length | 5000 мм |
| Section length | 27 мм |
| Colour rendering index | 90-100 (class 1A) |
| Design | Tape |
| Colour category | Neutral |
| Number of light sources per metre | 288 |
| Lamp voltage | 24 В |
| Lamp voltage up to | 24 В |
| Lamp voltage from | 24 В |
| Power consumption per metre | 12 Вт |
| Luminous flux per metre | 1300 лм |
| Mounting method | Surface mount |
| IP protection rating | IP66 |
| Lamp type | Non-replaceable LED |
| Lamp type | LED |
| Light beam distribution angle | 170 град. |
| Control device | Voltage-controlled LED control gear |
| Color | White |
| Light color | White |
| Color temperature at | 4200 К |
| Colour temperature from | 3800 К |
| Width | 10 мм |
