DKC
Flexible metal conduit DN 20mm in sealed PVC insulation, D_in 20.5 mm, D_out 25.5, with pulling thread, 50 m, color gray 6071R-020P DKC
SKU: 6071R-020P
ETIM: EC001179
12,799 ₽
Get back 127 ₽ in points
Order multiple: 50 м
Analogues by specifications
Stock by warehouse
Flexible metal pipes (flexible conduit) can be laid at a convenient angle, which increases the system's adaptability to various tasks and facilitates installation. Distinctive features of flexible conduits are flexibility and high strength. Coated with a dense PVC sheath, they provide ideal sealing (IP66/IP67) and protect the cable from most oils and acids. Galvanized steel flexible conduit with sealed PVC insulation is used for laying electrical, telephone, and television wires. A metal fish tape facilitates pulling the cable into the flexible conduit. Outer diameter 25.5 mm. Inner diameter - 20.5 mm. 50m per coil. Sheath color - grey.
Outer diameter
25.5 мм
Inner diameter
20.5 мм
Flexibility
Flexible
Use in hazardous areas
No
Material
Steel
2nd coating sheath material
Polyvinyl chloride (PVC)
Coating material - layer 1
Polyvinyl chloride (PVC)
Nominal diameter
20 мм
Compressive strength
1250 Н
Breaking force
1000 Н
Flame propagating
No
With pulling probe
Yes
IP protection rating
IP44
Operating temperature to
70 град.C
Operating temperature from
-45 град.C
Seal
Without seal
Color
Grey
Colour
Grey
