DKC
Mini feed-through terminal, screw clamp, 2 connection points, 2.5 sq.mm, gray TUR-M-2.5 DKC
SKU: TUR-M-2.5
ETIM: EC000897
50 ₽
Analogues by specifications
Stock by warehouse
No description available
Version tested for explosion protection "Ex e"
No
Internally linked levels
No
Minimum possible mounting height
32 мм
Length
28 мм
Number of terminals per level
2
Number of poles
2
Number of levels
1
Housing insulation material
Thermoplastic
Rated voltage
380 В
Rated current In
24 А
Closing plate can be fitted if required
Yes
Operating temperature
105 град.C
Operating temperature from
-40 град.C
Connection position
Side
Core cross-section
2.5 кв.мм
Flexible stranded conductor cross-section up to
2.5 кв.мм
Stranded flexible conductor cross-section from
Please provide the text you would like me to translate. кв.мм
Solid conductor cross-section to
4 кв.мм
Solid conductor cross-section from
Please provide the text you would like me to translate. кв.мм
Mounting method
DIN rail 15 mm
Electrical connection type 1
Screw connection
Color
Grey
Width/connection pitch
5.2 мм
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
