Mini-contactor MKE 16A 400V 1NO EKF PROxima Mctr-s-16-400
SKU: Mctr-s-16-400
ETIM: EC000066
2571 ₽
Price list (incl. VAT):
2315 ₽
Preorder
Order multiple: 100 шт
PROxima mini-contactors consist of a housing, fixed contacts mounted within it, and moving contacts mounted in the moving part of the magnetic system. The stationary part of the magnetic system is rigidly fixed in the mini-contactor housing. A spring prevents the contacts from closing. When voltage is applied to the control coil, a magnetic field is generated in the contactor's magnetic system, which, overcoming the spring resistance, closes the magnetic system and makes the contacts. When voltage is removed from the control coil, the spring opens the contacts. Commutation with aluminum and copper wire is possible.
| Number of auxiliary NO contacts | 1 |
| Number of auxiliary break contacts | 0 |
| Number of main NO contacts | 3 |
| Number of main NC contacts | 0 |
| Modular design | No |
| Rated switching power at AC-4, 400 V | 3 кВт |
| Rated operational current Ie at AC-4, 400 V | 6 А |
| Rated power at AC-3, 400 V | 7 кВт |
| Rated operational power (NEMA) | 4 кВт |
| Rated control supply voltage Us AC at 50 Hz up to | 440 В |
| Rated control supply voltage Us AC at 50 Hz from | 340...440 В |
| Rated control supply voltage Us DC up to | 0 В |
| Rated control supply voltage Us DC from | 0 В |
| Rated operational current Ie at AC-1, 400 V | 36 А |
| Rated operating current Ie at AC-3, 400 V | 16 А |
| Switch-on current type | AC (alternating) |
| Main electrical circuit connection type | Screw connection |
