EKF
Minsk 3-gang switch flush-mounted,10A, white EKF ERV10-024-10
SKU: ERV10-024-10
ETIM: EC001590
242 ₽
Price list (incl. VAT):
346 ₽
Available August 3
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
|
Remote warehouse
Available
|
52 | шт | August 3 | August 3 |
Select a warehouse to order
The EKF Minsk series three-gang switch is an excellent solution for apartments and country houses for lighting control. The compact mechanism simplifies installation. Fixed spreader legs securely fix the device in the mounting box.
| RAL number (similar) | 9 010 |
| Material type/grade | Thermoplastic |
| Spring-return push | No |
| Washing machine switch | No |
| Device height | 84 мм |
| Mounting installation depth | 19 мм |
| Device depth | 34 мм |
| Protective surface coating | Untreated |
| Number of actuator buttons | 3 |
| Switched fluorescent lamp current | 10 AX |
| Material | Plastic |
| Minimum depth of recessed mounting box | 19 мм |
| Cable trunking installation | No |
| Halogen-free | Yes |
| Rated voltage | 230 В |
| Rated current | 10 А |
| Backlight | No |
| Suitable for ingress protection IP | IP20 |
| With mounting plate | No |
| With label field | No |
| Status signalling contact | No |
| Mounting method | Internal / concealed |
| Connection method | Screw clamp/terminal |
| Switching/control type | Rocker/Button |
| Configuration type | Assembled with housing/frame |
| Fastening type | By expansion (tabs) and screws |
| Surface type | Glossy |
| Connection diagram type | Switch 3x1-pole |
| Color | White |
| Device width | 84 мм |
