Universal four-channel analog input module.
Measures universal signals: 4-20 mA, 0-5 V, 0-10 V.
Features input signal filtering.
Supports "hot swap". Convenient terminal blocks ensure ease of connection. Modbus address is set by microswitches on the front panel of the device.
Internal bus data transfer rate – 1 Mbps.
The module can be used as a standalone Modbus device provided it is connected via the OptiLogic L-BE-1 bus expansion module.
Operating temperature range – from -40°C to +55°C.
Built-in software is supplied as part of the equipment and is not sold separately.
| Resistance input | Yes |
| Resistance thermometer input | No |
| Thermocouple input | No |
| Input voltage | Yes |
| Input current | Yes |
| Height | 115 мм |
| Output, by voltage | No |
| Output, current | No |
| Depth | 64 мм |
| Number of analog inputs | 4 шт. |
| Number of analogue outputs | 0 шт. |
| Configurable analogue inputs | Yes |
| Configurable analogue outputs | No |
| Configurable input signal | Yes |
| Configurable output signal | No |
| Suitable for security systems | Yes |
| Connection type | Plug connector |
| Width | 41 мм |
