EKF
Discrete input module EMF 8 PRO-Logic EKF EMF-D-8X
SKU: EMF-D-8X
ETIM: EC001419
5754 ₽
Price list (incl. VAT):
9358 ₽
Available August 12
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
| Manufacturer warehouse | |||||
|
Manufacturer warehouse
Available
|
164 | шт | August 12 | clarifying | |
Select a warehouse to order
Devices designed to perform logic operations according to a given program. Capable of solving tasks of any complexity level. Used to increase energy efficiency, safety, and digitalization of enterprises in all fields of activity.
| DC voltage at digital input from | 20.4...28.8 В |
| SIL in accordance with IEC 61508 | 2 |
| Weight | 0.2 кг |
| Wall/surface mounting possible | No |
| Busbar mounting possible | Yes |
| Signal change delay time to | 5 мс |
| Signal change delay time from | 0...5 мс |
| Input signal current 1 | 0.01 мА |
| Height | 95 мм |
| Height | 95 мм |
| Galvanic isolation | Yes |
| Depth | 79 мм |
| Additional equipment (Ex ia) | No |
| Additional equipment (Ex ib) | No |
| Permissible input voltage to | 28.8 В |
| Permissible input voltage from | 28.8...28.8 В |
| Category per EN 954-1 | 2 |
| Gas explosion protection category (EU ATEX directives) | No (without) |
| Dust explosion protection category (EU ATEX Directive) | No (without) |
| Number of "fast" digital inputs (of total) | 0 |
| Number of HW USB interfaces | 0 |
| Number of industrial Ethernet HW interfaces | 0 |
| Number of HW serial RS-485 interfaces | 0 |
| Number of digital inputs | 8 шт. |
| Configurable digital inputs | Yes |
| Maximum power consumption | 4.8 Вт |
| Minimum duration of a single input pulse | 0.8 мс |
| DC supply voltage to | 28.8 В |
| DC supply voltage from | 20.4...28.8 В |
| DCON protocol support | No |
| MODBUS protocol support | No |
| TCP/IP protocol support | No |
| OWEN protocol support | No |
| Suitable for security systems | No |
| Operating temperature | 55 град.C |
| Operating temperature from | 0...55 град.C |
| Input voltage current type | DC (direct) |
| Supply voltage current type | DC (direct) |
| With relay output | No |
| Certified per IEC 61508 | No (without) |
| Ingress protection (IP) of front side | IP20 |
| Memory type | Flash |
| Connection type | Spring clamp connection |
| Digital output type | No (without) |
| Performance level per EN ISO 13849-1 | Level c |
| Digital input "220V" | No |
| Digital input "24V" | Yes |
| Digital input "NPN" | Yes |
| Digital input "PNP" | Yes |
| Digital input "SK" | No |
| Conductometric digital input | No |
| Width | 25 мм |
