Keystone Jack RJ-45(8P8C) UTP unshielded cat.5e 90deg type white PRO Rexant 02-0064

Connection module (Keystone Jack) is used for installation in modular patch panels, wall socket enclosures, and for installation in Mosaic-type modular inserts. The module provides efficient connection of equipment and workstations to the information network. The REXANT Keystone module complies with ISO/IEC 11801, TIA/EIA-568, EN 50173 standards. It is made of high-quality durable materials, which significantly increases its service life compared to standard modules. Housing material – ABS plastic, which has high impact resistance and complies with the UL-94V-0 standard. Spring contacts are made of phosphor bronze and are gold-plated with a thickness of 1.27 μm (50µ”). IDC type contacts are made of phosphor bronze and have a tin alloy coating with a thickness of 2.54 μm. Design features: category marking on the front side, color coding in accordance with T568B and T568A. Supported applications: 10BASE-T, 100BASE-TX, 100BASE-T4, 1000BASE-T. Technical characteristics: Bandwidth: 100 MHz Termination type: type 110 Contact resistance: no more than 20 mOhm Insulation resistance: no less than 500 MOhm Connectable conductors: single-core 22-26 AWG Number of connections: no less than 750 cycles Connector retention force: 50N/1 min
