EKF
Discrete signal expansion module PRO-Relay 4DI 4DO(R) AC EKF PRL-E-4DI4DO-R-AC
SKU: PRL-E-4DI4DO-R-AC
ETIM: EC001419
6,924 ₽
Get back 69 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
No description available
AC voltage at digital input from
110...240 В
AC voltage at "Relay" digital output from
0...250 В
DC voltage on digital output "Relay" from
0...30 В
SIL in accordance with IEC 61508
2
Weight
0.145 кг
Wall/surface mounting possible
Yes
Busbar mounting possible
Yes
Signal change delay time to
120 мс
Signal change delay time from
0...120 мс
Input signal current 1
0.06 мА
Height
90 мм
Height
90 мм
Output current
1 А
Galvanic isolation
No (without)
Depth
61 мм
Additional equipment (Ex ia)
No
Additional equipment (Ex ib)
No
Permissible input voltage to
240 В
Permissible input voltage from
240...240 В
Permissible output voltage at
250 В
Permissible output voltage from
0...250 В
Short-circuit protection, available outputs
No
Category per EN 954-1
1
Gas explosion protection category (EU ATEX directives)
No (without)
Dust explosion protection category (EU ATEX Directive)
No (without)
Number of "fast" digital inputs (of total)
0
Number of "fast" digital outputs (of total)
0
Number of HW USB interfaces
0
Number of industrial Ethernet HW interfaces
0
Number of HW serial RS-485 interfaces
0
Number of digital inputs
4 шт.
Number of digital outputs
4 шт.
Number of digital outputs "Relay"
4
Number of "Triac" digital outputs
0
Number of digital outputs "Transistor"
0
Number of digital outputs "External SSR control"
0
Configurable digital inputs
No
Configurable digital outputs
Yes
Maximum power consumption
1.35 Вт
Minimum duration of a single input pulse
20 мс
AC supply voltage 50 Hz to
240 В
AC supply voltage 50Hz from
110...240 В
DCON protocol support
No
MODBUS protocol support
No
TCP/IP protocol support
No
OWEN protocol support
No
Suitable for security systems
No
Operating temperature
55 град.C
Operating temperature from
-20...55 град.C
Input voltage current type
AC (alternating)
Output voltage current type
AC/DC
Supply voltage current type
AC (alternating)
With relay output
Yes
Certified per IEC 61508
No (without)
Ingress protection (IP) of front side
IP20
Memory type
Flash
Connection type
Screw connection
Digital output type
Relay
Current at "Relay" digital output from
0...10 А
Performance level per EN ISO 13849-1
Level c
Digital input "220V"
Yes
Digital input "24V"
No
Digital input "NPN"
Yes
Digital input "PNP"
No
Digital input "SK"
No
Conductometric digital input
No
Digital output "Relay"
Yes
Digital output "Triac"
No
Digital output "Transistor"
No
Digital output "External SSR control"
No
Width
40 мм
