КЭАЗ
Relay module OptiRel G RM38-51-24D-6-V-CO KEAZ 280988
SKU: 280988
ETIM: EC001437
789 ₽
Price list (incl. VAT):
789 ₽
Available August 7
Order multiple: 10
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
|
Transit warehouse
Available
|
1 | шт | August 7 | clarifying |
Select a warehouse to order
RM38 relay modules are an assembly of RP34 plug-in relays and RR93 socket (base).
These devices are the most compact solutions in the OptiRel G range, as they have a housing width of only 6 mm, allowing a large number of relays to be installed in a single row of limited width.
Equipment of this series is primarily used for signal amplification and conversion between sensors/actuators and PLCs, mechanisms, or industrial buses, and also provides reliable electrical isolation for these sensitive electronic devices.
This model is equipped with standard contacts made of silver-nickel alloy (AgNi).
| Supplied with socket | Yes |
| Type of changeover contacts | Single contact |
| Height | 88.5 мм |
| Depth | 76.4 мм |
| Number of normally closed (NC) contacts | 0 |
| Number of normally open (NO) contacts | 0 |
| Number of switching contacts | 1 |
| Rated control supply voltage Us AC at 50 Hz up to | 0 В |
| Rated control supply voltage Us AC at 50 Hz from | 0 В |
| Rated control supply voltage Us DC up to | 24 В |
| Rated control supply voltage Us DC from | 24 В |
| Rated current | 6 А |
| Polarization | Defined polarity |
| Switch-on current type | Direct current (DC) |
| With positively driven contacts | No |
| With removable terminals, clamps | No |
| IP protection rating | IP20 |
| Connection type | Screw connection |
| Switching characteristics | Monostable |
| Width | 6.3 мм |
