Cable termination 1PKNT-10-35/50 69548 KVT

• Designed for terminating single-core cables: • with cross-linked polyethylene insulation and copper wire screen • for voltage 6 and 10 kV • Complies with the requirements of GOST 34839-2022 • Included in the Ministry of Industry and Trade register • Cable types for installation: (A)PvP, (A)PvV, (A)PvPu, (A)PvPg, (A)PvPug, (A)PvP2g, (A)PvPu2g • The presence of an electric field stress relief tube ensures the reliability of high-voltage joints by uniformly distributing the electric field stress in the semiconductor screen cut area • The anti-tracking tube material is resistant to tracking, ultraviolet rays, and weather conditions • The joint is equipped with a core insulator that increases the leakage current path and creates a dry zone on the surface of the joint • Hot-melt adhesive applied to the inner surface of the anti-tracking tube and the winding of sealant tape at the wire screen outlet ensure complete sealing of the joint after installation • The grounding wire is formed directly from the copper wire screen of the cable and is terminated with a crimp sleeve • When installing the grounding unit on a cable with armor made of steel or aluminum wires, it is necessary to additionally use the "KMPB Grounding Kit" corresponding to the selected joint. • The joint kit is universal and allows the use of both crimp cable terminals and bolt terminals • The delivery set is designed for the installation of a three-phase cable • Note: 1PKNT-10-800(B) joints are designed for installation only on cables with aluminum conductors • Installation tools: PG (KVT) propane torch, NMB-6 (KVT) bolt terminal and connector head removal kit, insulation and semiconductor screen removal tools • All polymer compositions used for the production of KVT heat-shrinkable components are halogen-free (HF=Halogen Free) • Manufactured according to TU 3599-005-97284872-2015 * Prices are indicated per 1 joint (shipment is carried out in multiples of 3 joints)
